Description	First synth simulating physical strings, wind and reed sounds, also simple synth sounds (since V2.0). special FX and controller table for controller adaption. Special parmeters: driver and resonators like blowing a string and bowing a flute. 3 editors on Macs OS9 needed to really edit it. Lots of EQs and FX. Structure: Driver - Resonator - Modifier und Pipe/String + FX with special Envelopes (most with initial Levels). 5 delays make one part of the modifier as another resonator. Since PM is based on Delays there are several dampers, filters and delay/reso controls. V2: parameters updated and more suitable for "non real" sounds (recommended!) Also as Rack version VL1m
Brand	Yamaha
Model	VL1
Device	Synth
Type	Keys
Engine Type	Digital
Engine	PM
Voices (max)	2
Multitimbral	1
Oscillators	2
LFO	1 triangle saw square
Filter (VCF)	1 Dynamic Filter (LPF, HPF, BPF, BEF, with resonance)
Envelope (VCA)	6 Envelope Generators 2x AADSR 1xIHAIDR 1x DAS 2xD
FX	Flanger, pitch change, distortion, Feed back delay. Reverberation.
Memory	128 patches
Keys	49
Key type	Keys
Velocity	Y
Aftertouch	Channel
Midi	I-O-T
Produced:	1994 - 1994

Legend:		Obvious	Y: Yes, N: No, N/A: Not Applicable
VCO	Voltage Controlled Oscillator	DCO	Digital Controlled Oscillator
LFO	Low Frequency Oscillator	Sub	Sub Oscillator
VCF	Voltage Controlled Filter	VCA	Voltage Controlled Amplifier
Velocity	As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key.	Aftertouch	Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel.
Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise.
