Description | If you're looking for a full-size keyboard with great sounds and exceptional touch, the S90 has just what you need-and nothing you don't. It's perfect for those who simply want all the award-winning MOTIF's high quality sounds and one of the world's most expressive three-layer piano sounds all in an affordable, portable 88-note weighted synthesizer. it lacks the sequencer and sampling of the MOTIF. |
| Brand | Yamaha |
| Model | S90 |
| Device | Synth |
| Type | Keys |
| Engine Type | Digital |
| Engine | AWM2 |
| Voices (max) | 64 |
| Multitimbral | 16 |
| Oscillators | 4 |
| FX | Reverb 12 Types, Chorus 25 Types, Insertion 1 x 25 types, Insertion 2 x 104 types, Master Effect Variation x 25 types (available for Performance/Song), Master EQ, 5 Bands. |
| Memory | 384 preset + 128 GM. 128 user |
| Drums | 48 + 1(GM) Drumkits, 16 user |
| Arpeggiator | 256 preset, 128 user |
| Keys | 88 |
| Key type | Keys, Hammer action |
| Velocity | Y |
| Aftertouch | Channel |
| Midi | I-O-T, USB |
|
Produced: | 2002 - 2002 |
| Legend: |
Obvious |
Y: Yes, N: No, N/A: Not Applicable |
| VCO |
Voltage Controlled Oscillator |
DCO |
Digital Controlled Oscillator |
| LFO |
Low Frequency Oscillator |
Sub |
Sub Oscillator |
| VCF |
Voltage Controlled Filter |
VCA |
Voltage Controlled Amplifier |
| Velocity |
As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. |
Aftertouch |
Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. |
