Yamaha | DX100

Description

The DX100 is a small and portable budget DX synthesizer from Yamaha. Like all DX's it uses (FM) Frequency Modulation synthesis. It's not the easiest form of synthesis to program but can result in some excellent sounds. The DX100 is not as flexible nor powerful as a DX7, but it does have some cool sounds. It is most renowned for its great analog bass sound (Patch #01) that is awesome for techno, house, jungle, and acid music styles; it's very gritty, the bass tone with gristle! However, any other preset sounds that you'll find in the DX100 are pretty bad and require editing for anything else useable.

The DX100 has mini-keys and only 49 of them. No filters, arpeggiators, effects or programmable controllers are available either. Small pitch and mod wheels in the upper left and guitar strap pegs make this synth usable for live use if you're feeling whimsical. If you mess around with the settings on Parameter 13, even if you don't know anything about FM, you can get some seriously twisted sounds out of it. If you're willing to spend a little time with it, it has a lot more potential than just that one bass sound that people will eventually get sick of. And at its currently low street price, it just might be worth getting.

BrandYamaha
ModelDX100
DeviceSynth
TypeKeys
Engine TypeDigital
EngineFM
Voices (max)8
Multitimbral1
Oscillators4
Engine Detailed16 bit Digital 4 operator FM. 8 algorhythms.
Memory192 preset, 24 user
ControllersBreath controller
Keys49
Key typeMini keys
VelocityN
AftertouchN
MidiI-O-T
Extra infoGuitar strap pegs to use it as a Keytar
Produced:1985 - 1985
Legend: Obvious Y: Yes, N: No, N/A: Not Applicable
VCO Voltage Controlled Oscillator DCO Digital Controlled Oscillator
LFO Low Frequency Oscillator Sub Sub Oscillator
VCF Voltage Controlled Filter VCA Voltage Controlled Amplifier
Velocity As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. Aftertouch Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel.
Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise.
