Yamaha | CS60 |
|
Description | The CS-60 is a very scaled down light version of the CS-80. It's a classic and old polyphonic programmable analog synthesizer that has some potential. It does not sound as great as the CS-80 nor is it as programmable. You get a few preset sounds which are pretty useless and a mere 1 user patch. But there are just enough sliders, edit parameters and even an excellent Ring Modulator to get some interesting pads, drones, basses and other analog synth sounds. Oddly, sitting between the keyboard and those large Preset Switches is a long velvet ribbon controller which is pretty cool for doing wild pitch bends. Due to its old age most CS-60s are in battered shape these days, difficult to service but in need of some. And they suffer common ailments of the analog domain - overheating, unstable tuning, it weighs a lot, etc... However the CS-60 is the cheapest way to get into some genuine CS-80 sounds of analog heaven with basic entry-level programming! |
| Brand | Yamaha |
| Model | CS60 |
| Device | Synth |
| Type | Keys |
| Engine Type | Analog |
| Engine | VCO |
| Voices (max) | 8 |
| Oscillators | 1 |
| Sub | 1 |
| LFO | Yes |
| Noise | Y |
| Engine Detailed | 1 VCO per voice (square and saw plus PWM; 1 sub-osc with 4 wave types; noise gen) |
| Filter (VCF) | High- and low-pass with resonance and ADSR envelope |
| Envelope (VCA) | ADSR |
| FX | Ring Modulator |
| Memory | 12 Presets + 1 user |
| Keys | 61 |
| Key type | Keys |
| Velocity | N |
| Aftertouch | Channel |
| CV-gate | CV/Gate |
| Produced: | 1977 - 1977 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
