Siel | MDP-40 |
|
Description | Siel MDP-40 Drum Machine was sold in the mid-80s to compete with booming drum machine market. It features 10 pads, for 13 PCM sounds, 3 of which are accessible by external MIDI only. The design was also sold under other brands as the Suzuki RPM-40 and the Keytek MDR-40. |
| Brand | Siel |
| Model | MDP-40 |
| Device | Drum |
| Type | Desktop |
| Engine Type | Digital |
| Engine | ROM |
| Voices (max) | 10 |
| Multitimbral | 10 |
| Drums | 10 instrument sounds: bass drum, low tom, snare, rim shot, closed hi-hat, open hi-hat, cymbal, cabasa, cow bell, hand clap |
| Sequencer | 40 pre-programmed styles: disco, funky, rock, 8-beat, ballad, beguine, bossa, jazz, polka, tango, new wave , reggae, pop, 16-beat, super rock, cha-cha, samba, shuffle, march, waltz |
| Keys | 10 |
| Key type | Pads |
| Velocity | N |
| Aftertouch | N |
| Midi | I-O-T |
| Produced: | 1986 - 1986 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
