Siel | DK80 |
|
Description | The Siel DK-80 is an odd synth that could be said to bridge the gap between low end mid-eighties Roland and Sequential type synthesizers. It is an analog synth with digital control. It is also bi-timbral with a split keyboard mode giving you 2 polysynths in one keyboard! The sounds are OK, and the DK-80 makes a great backup synth. It has an on-board two-track sequencer, chord memory and hold, programmable stereo panning and sweeping. Parameters are edited one at a time and via membrane push buttons. For a fair price the DK-80 is certainly an exotic addition to any synth set up but may be too limited to use as your main or only analog synth. It also generously had 2 filters, 4 LFO's, and, 14 digital envelopes. The unit also has a 2 track sequencer 300 note sequencer and a chorus effect. It's user interface is very similar to Korg's Poly 800 and EX model of synthesizers. |
| Brand | Siel |
| Model | DK80 |
| Device | Synth |
| Type | Keys |
| Engine Type | Analog |
| Engine | DCO |
| Voices (max) | 12 |
| Multitimbral | 2 |
| Oscillators | 2 |
| LFO | 2 |
| Noise | Y |
| Engine Detailed | 2 DCO's (sine, sqr, tri), 1 pink noise gen |
| Filter (VCF) | 2 24 dB/octave low pass VCFs |
| Envelope (VCA) | 2 six point envelope generators |
| Memory | 40 preset, 10 user (50 external programs via RAM pack, 100 external programs via ROM pack) |
| Recording | 2 track polyphonic sequencer. |
| Keys | 61 |
| Key type | Keys |
| Velocity | Y |
| Aftertouch | N |
| Midi | I-O-T |
| Produced: | 1985 - 1985 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
