Description	The U-110 is a basic rack-mount sound module consisting of acoustic-oriented PCM samples with preset settings, limited flexibility, and boring late eighties sounds. It's nothing to get excited about. It has 2MB of ROM-based sampled sounds, none of which sound great. The U-110 is fairly noisy as well. Its palette of sounds could be grossly expanded with up to four expansion cards, but good luck finding those today! The U-110's biggest distinction, really, is that it was Roland's first totally digital sample-based synth. At the time, that was a break-through - look at all the realistic sounds you get in a single rack space MIDI module! Nowadays, it's hard to wonder why anybody would want one of these. The U-110 was available in a prototype form as the T-110. But the U-110 was soon replaced by the U-20 keyboard and U-220 module.
Brand	Roland
Model	U110
Device	Synth
Type	Rack
Engine Type	Digital
Engine	PCM
Voices (max)	30
Multitimbral	6
Engine Detailed	2MB ROM samples, expandable to 4MB
Envelope (VCA)	Amp envelope attack/release can be edited, among the limited parameters.
FX	2 FX - chorus and auto-pan
Memory	64 Presets. Expandable with PCM cards: Up to 4 cards can be used simultaneously.
Keys	0
Key type	N/A
Velocity	N/A
Aftertouch	N/A
Midi	I-O-T
Produced:	1988 - 1988

Legend:		Obvious	Y: Yes, N: No, N/A: Not Applicable
VCO	Voltage Controlled Oscillator	DCO	Digital Controlled Oscillator
LFO	Low Frequency Oscillator	Sub	Sub Oscillator
VCF	Voltage Controlled Filter	VCA	Voltage Controlled Amplifier
Velocity	As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key.	Aftertouch	Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel.
Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise.
