PPG | 1002 |
|
Description | The first keyboard PPG released the 1002 (VCO) and 1020 (DCO) mono synthesizer for musicians looking for a performance oriented lead synthesizer. |
| Brand | PPG |
| Model | 1002 |
| Device | Synth |
| Type | Keys |
| Engine Type | Analog |
| Engine | VCO |
| Voices (max) | 1 |
| Oscillators | 2 |
| LFO | 1 Square, Triangle |
| Noise | Y |
| Engine Detailed | 2 VCO, Pulse Variable, Saw Up, Square, Triangle, White Noise |
| Filter (VCF) | 1 24dB Slope (4-pole), Low Pass, Resonance |
| Envelope (VCA) | 1 ADR |
| Keys | 49 |
| Key type | Keys |
| Velocity | N |
| Aftertouch | N |
| CV-gate | CV/GATE I-O |
| Extra info | About 100 made |
| Produced: | 1976 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
