Description | The Sub 37 Tribute's new features include Duo Mode, which allows oscillator 1 and oscillator 2 to be played independantly, programmable arpeggiator/step sequencer, two modulation busses with assignable source and destination options, access to 256 presets, and a 37-note velocity sensitive keyboard with aftertouch.
A fully featured mixer section contains dedicated controls and mutes for each sound source, as well as a level control for External audio input and Feedback - which feeds the output of the filter directly back to the input of the mixer.
Also included are the powerful DAHDSR envelopes from the Sub Phatty with panel control of each extended function.
The Tribute edition includes Bob Moog signature panel, Wood sides, and Aluminum extrusion
|
| Brand | Moog |
| Model | Sub 37 |
| Device | Synth |
| Type | Keys |
| Engine Type | Analog |
| Engine | VCO |
| Voices (max) | 2 |
| Oscillators | 2 |
| Sub | 1 |
| LFO | 1 Sample & Hold, Saw Up, Saw Down, Square, Triangle |
| Noise | Y |
| Engine Detailed | 2 VCO, Saw Down, Saw Up, Square, Sub Oscillator, Triangle, White Noise |
| Filter (VCF) | 1 6dB Slope, 12dB Slope (2-pole), 18dB Slope, 24dB Slope (4-pole), High Pass, Low Pass, Resonance |
| Envelope (VCA) | 2 DAHDSR |
| Memory | 256 patches |
| Sequencer | Yes |
| Arpeggiator | Yes |
| Keys | 37 |
| Key type | Keys |
| Velocity | Y |
| Aftertouch | Channel |
| Midi | I-O, USB |
| CV-gate | CV/GATE, DIN |
| Extra info | Limited Tribute edition includes Bob Moog signature panel, Wood sides, and Aluminum extrusion. |
|
Produced: | 2014 - 2017 |
| Legend: |
Obvious |
Y: Yes, N: No, N/A: Not Applicable |
| VCO |
Voltage Controlled Oscillator |
DCO |
Digital Controlled Oscillator |
| LFO |
Low Frequency Oscillator |
Sub |
Sub Oscillator |
| VCF |
Voltage Controlled Filter |
VCA |
Voltage Controlled Amplifier |
| Velocity |
As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. |
Aftertouch |
Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. |
