Modal | CRAFTsynth |
|
Description | The Modal CRAFTsynth is a digital monophonic synthesizer kit which can be assembled (without need to solder) in less than 10 minutes. For a small format synth kit, the Modal CRAFT features some advanced features usually only found in much higher priced synths. The CRAFTsynth features 2 oscillators per voice, Sine, Tri, Saw, PWM, Noise and FM and an LFO with six destinations, including VCA amplitude, filter cutoff and PWM. Don’t let the size of this synth fool you into thinking it sounds small, it certainly does not. Easy Self-Assembly The Modal CRAFTsynth Monophonic Synthesizer Kit allows you to build up the synthesizer from 5 separate boards, with its simple yet effective design making it easy to assemble. The assembly process requires no soldering, tools or specialist knowledge, everything you need comes straight out of the box and allows you to slot the pieces together with ease. You can assemble the synthesizer within 10 minutes, giving you a hands-on experience when it comes to building your synth. Powerful Monophonic Performance The CRAFTsynth features 2 oscillators per voice with a range of controls for in-depth manipulation such as detune and fine detune for OSC 2 as well as a selection of different waveforms including: Sine, Tri, Saw PWM, Noise and FM (OSC2 modulates pitch of OSC1). This versatile range of controls allows you to sculpt your own synth sounds with ease. The LFO features six destinations in total including: VCA amplitude, filter cutoff, FM amount, OSC mix, PWM amount and pitch/frequency. This wide range of parameters allows you to create your own sounds with extreme precision, giving you in-depth control over every part of the sound. There is also a mixer stage of OSC levels, allowing you to further edit your sound for added depth and clarity. The Unison/Spread mode splits the oscillators into four separate sub oscillators per oscillator, virtually expanding your synth to a total of eight oscillators which are also de-tunable for a massive sound. The Modal CRAFTsynth is also fully class compliant, meaning it can be controlled by a wide range of popular DAWs, offering seamless integration for your favourite programs and applications. LFOs and Presets The Modal CRAFTsynth features four LFO wave forms in total, with each LFO being invertible for added versatility. The LFO wave forms are as follows; Sine, Tri, Saw, Square. This standard range of LFOs allows you to create everything from atmospheric pads to in-your-face leads and more. The resonant low pass filter can become state variable when using the CRAFTapp (available end of 2016). The CRAFTapp that comes included with the synthesizer allows you to get in-depth with your synthesis, giving you the ability to control custom enveloped, low pass filters and more. Intuitive Layout The highly intuitive layout of the Modal CRAFTsynth places everything you need right at your fingertips. The eight front panel potentiometers offer unparalleled editing control with two pages of editing functionality, allowing you to control parameters with precision. The CRAFTsynth also features 16 path storage locations (expandable through CRAFTapp) as well as 16 recallable EG presets for ease of use (full editing control with CRAFTapp). The playable touch panel interface features five note keys plus controls for scale and glide time. The touch panel interface’s keys are clearly labelled with its primary function giving you the ability to change between scales and more. Delay and distortion effects are also included for adding harmonics and texture to your sound. A Headphone and Line output are included for direct monitoring as well as outputting the CRAFTsynth to speakers and other audio devices. The synthesizer itself is powered via a USB cable or an optional AA battery pack. |
| Brand | Modal |
| Model | CRAFTsynth |
| Device | Synth |
| Type | Desktop |
| Engine Type | Digital |
| Engine | VA |
| Voices (max) | 1 |
| Multitimbral | 1 |
| Oscillators | 2 |
| LFO | 1 Saw Down, Sine, Square, Triangle, Clocked |
| Engine Detailed | 2 OSC, Pulse Variable, Saw Down, Sine, Square, Triangle, White Noise. OSC's can be split in 4 subs per oscillator. |
| Filter (VCF) | 1 24dB Slope (4-pole), Band Pass, Low Pass, Resonance |
| Envelope (VCA) | 2 ADSR |
| FX | Delay and distortion |
| Memory | 16 Patches, 16 EG settings |
| Keys | 5 |
| Key type | Touch plates |
| Velocity | N |
| Aftertouch | N |
| Midi | USB |
| Produced: | 2016 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
