The Ultimate SynthDB | Korg Poly-61 (M)

Browse

Description
Brand	Korg
Model	Poly-61 (M)
Device	Synth
Type	Keys
Engine Type	Analog
Engine	DCO
Voices (max)	6
Multitimbral	2
LFO	1 LFO can modulate the DCOs or the Filter
Engine Detailed	DCO1:sawtooth, pulse, and square; DCO-2: sawtooth, square
Filter (VCF)	1 lowpass filter w/ ADSR
Envelope (VCA)	ADSR
FX	Chorus
Memory	64 patches
Arpeggiator	Arpeggiator with external sync
Keys	61
Key type	Keys
Velocity	No
Aftertouch	No
Midi	I-O (on later Poly-61M models)
Produced:	1982 - 1986

Legend:		Obvious	Y: Yes, N: No, N/A: Not Applicable
VCO	Voltage Controlled Oscillator	DCO	Digital Controlled Oscillator
LFO	Low Frequency Oscillator	Sub	Sub Oscillator
VCF	Voltage Controlled Filter	VCA	Voltage Controlled Amplifier
Velocity	As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key.	Aftertouch	Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel.
Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise.
