Clavia | Nord Lead 3 Rack |
|
Description | Newly redesigned and vastly improved, Clavia gives us the Nord Lead 3 Rack. It is a 24-voice synthesizer (the NL2 is 16-voice) with many new features including many bigger knobs and controls. A new Unison mode is available that won't affect polyphony so that you can get some extremely thick and fat polyphonic sounds. A new and 'easier to use' user interface with endless rotary knobs and LED graphs offer total and immediate control. The oscillator section has been completely redesigned. There are two separate oscillator groups, each providing you with six different waveforms, plus an additional built-in sync oscillator. A new type of synthesis akin to FM is also available called Sinus Modulation (SM). The Nord Lead 3 Rack also features two high quality multi-mode filters with Low-, Band- and High-pass filtering. There's also Lowpass-Highpass and Lowpass-Lowpass filter modes and a Classic mode that emulates the characteristics of a classic analog filter. The Nord Lead 3 Rack now offers up to 3 LFOs/Envelopes per voice plus Global Vibrato, syncable to MIDI clock. The Nord Lead 3 Rack also has four separate Morph groups. The Morph function lets you continuously control defined ranges of up to 26 parameters in a sound, using only a single control source. This lets you produce radical changes to a sound in a very fast and easy way. There are four Morph groups available for each sound and you may assign up to 26 different parameters, distributed as you wish among the four Morph groups. The Morph groups are hardwired to one control source each: Velocity, Aftertouch, Modulation Wheel and Expression Pedal. And with the new Timbre function you can switch between two complete parameter setups in a sound. Also on-board are 4 individual audio outputs. Each MIDI part can be routed to a separate output or to two for stereo. The Software within the Nord Lead 3 Rack can easily be upgraded via MIDI for future enhancements and upgrades. The Nord Lead 3 Rack makes a great synth better than ever. |
| Brand | Clavia |
| Model | Nord Lead 3 Rack |
| Device | Synth |
| Type | Rack |
| Engine Type | Digital |
| Engine | VA |
| Voices (max) | 24 |
| Multitimbral | 4 |
| Oscillators | 2 |
| LFO | 2 per voice, syncable to MIDI. Triangle, saw, square, smooth and stepped random, and triple-peak sine waveforms. Seperate vibrato effect. |
| Noise | Y |
| Engine Detailed | 2 oscillator groups each with Six waveforms: sine, saw, triangle, square (pulse with width modulation), noise, synced noise, dual sine; 2- and 4-op FM and differential FM; osc-sync; ring-modulation; variable unison. |
| Filter (VCF) | 2 multi-mode filters (series or parallel). Lowpass, Bandpass, Highpass, LP-HP, LP-LP and Classic mode. 1-, 2-, or 4-pole. |
| Envelope (VCA) | ADSR envelopes for amplitude and filter; Amplifier Gain control |
| Memory | 1,024 patches, 256 performances |
| Keys | 0 |
| Key type | N/A |
| Velocity | N/A |
| Aftertouch | N/A |
| Midi | I-O-T |
| Produced: | 2001 - 2001 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
