|Engine Detailed||additive synth section: 5 PCM tones: piano, brass ensemble, trumpet, synth drums, human voice; 3 synth tones: flute, pipe organ, jazz organ|
|Sampler||Holds 1 Sample: 8-bit PCM, 9.38kHz, approx. 1.4 seconds, loop/ envelope select functions|
|Envelope (VCA)||13 Envelope shapes|
|Memory||11 drum patterns: disco, rock, pops, march, samba, bossa nova, rhumba, 4 beat, swing, slow rock, waltz|
|Recording||100 steps of polyphonic programming or 99 step chord sequence with and 198 steps each of two solo voices.|
|Key type||Mini keys|
|Extra info||Volatile so no way to save the sample or recording. Later models like SK-5, SK-8 and other models where available.|
Produced:||1985 - 1985
||Y: Yes, N: No, N/A: Not Applicable
||Voltage Controlled Oscillator
||Digital Controlled Oscillator
||Low Frequency Oscillator
||Voltage Controlled Filter
||Voltage Controlled Amplifier
||As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key.
||Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel.
|Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise.
